Pump

Centrifugal Pump are high-efficient, power-saving and compact in structure, convenient to operate and maintain .The hydraulic characteristic is with high head and small capacity. They are suitable for both domestic and industrial applications to convey clean water and non-aggressive chemical liquid, also can be applied to supply the water for garden, hotel, villas and agricultural irrigation, etc.

Classification of Pump

live demonstration of pump

1. according to structure, it can be divided into three-foot pump and four-foot pump

2. according to material, there are SUS304 and SUS316L

3. according to motor species, it can be divided into ordinary motor, ABB motor and explosion-proof motor.

Usages of Pump

    This stainless steel pump is applied to pumping such liquid which is clean, no solid matter or frictional matter, low viscous, noncorrosive, non-crystallizable, chemically neutral and close to water. Such as:
    1. Tank filling
    2. Domestic water supply
    3. Water transfer
    4. Pressure boosting
    5. Irrigation

Characteristics of Pump

Model	Flow(m³/h)	Height of extrusive liquid(m)	Motor ower(Kw)
BAW-1	1	9	0.37
BAW-3	3	18	0.75
BAW-5	5	24	1.5
BAW-10	10	24	2.2
BAW-15	15	32	3
BAW-20	20	36	4

Notes:

1. The parameters of stainless steel pump in diagram are standard configuration, any other requirements, please put forward.

2, the process parameters need provided: the material properties, flow, special requirements, etc.

Pump Finished Picture
