Mini multi-function Distillation, Concentration, Deposition and Recycle Machine-group

The unit is the new product researched and developed by our factory on the basis of referring to the same products from home and abroad. It integrates multifunctional extraction, vacuum concentration and solvent recycling and simplifies the operation procedure. At the same time, the extraction, concentration and recycling are carried out in a sealed flow circuit.

Usages of multi-function Recycle Machine-group

It is widely used in Chinese herbal medicine, herbal plants, animals, medicine, food additives, chemical engineering, etc.

Characteristics of multi-function Recycle Machine-group

It has avoided the occurrence of “running”, “protruding”, and “l(fā)eaking”， and the medicine residue can adopt electric lifting to output the material, which can improve the working environment and reduce the energy consumption. The parts of the unit that contact to materials are all made of stainless steel, which is in accordance with GMP standard.

Technical Parameters of multi-function Recycle Machine-group

Model	Extractor			Contractor				Vacuum pump		Water pump	Lift
Model	Volume （L）	Jacket working pressure （Mpa）	Vessel working pressure （Mpa）	evaporation（kg）		Vacuum degree （Mpa）	Working pressure of heater （Mpa）	Voltage （V）	power（KW）	power（KW）	power(KW)
TNH-50	65	0.15	Normal pressure	20	-0.018		0.09	380	3	0.75	0.25
TNH-100	125	0.15	Normal pressure	50	-0.018		0.09	380	3	0.75	0.25
TNH-200	250	0.15	Normal pressure	100	-0.018		0.09	380	3	0.75	0.25
TNH-300	375	0.15	Normal pressure	150	-0.018		0.09	380	3	0.75	0.25
TNH-400	475	0.15	Normal pressure	200	-0.018		0.09	380	3	0.75	0.25

Notes:

The technical parameters in the chart is standard configuration. Any specific requirements, please let us know.

multi-function Recycle Machine-group Finished Picture
